[Grasshopper]How to model a smartphone [Data download available]

grasshopper EN

In this article, we introduce how to model a smartphone in Grasshopper.


↑Youtube Channel

Model Image


The above 3 images show the overall shape of the model.

最終レンダリング

The images above show the final rendering.

For more details, please check the component images or download the data below.

Click here to download the Grasshopper file

Please refer to the Terms of Use regarding the use of downloadable data.

Grasshopper recipe

1: Rectangle 2: Surface 3: Unit Z 4: Extrude 5: Deconstruct Brep 6: Length 7: Series 8: Curve Middle 9: Deconstruct 10: Sort List 11: Delete Consecutive 12: List Item 13: Equality 14: Dispatch 15: Fillet Edge 16: Area 17: Offset Curve 18: Negative 19: Explode 20: Subtraction 21: Shatter 22: End Points 23: Line 24: Join Curves 25: Fillet 26: Construct Domain 27: Circle 28: Surface Split 29: Solid Difference 30: Brep 31: Cull Index 32: Unit Y 33: Unit X 34: MD Slider 35: Evaluate Surface 36: Multiplication 37: Linear Array 38: Construct Plane 39: Mirror 40: Addition 41: Merge


component1

Click to zoom

This time, as shown in the image above, there are a large number of components, so the image will not be displayed.

Therefore, we recommend downloading the data to check it or confirming it through the video, etc.
